Orthographic Projection (1947)
The film explains orthographic projection, a method used in engineering drawing to represent three-dimensional objects through two-dimensional views. It describes how different perspectives (front, top, side) reveal various dimensions and features of an object, including hidden aspects represented by dotted lines. The importance of understanding the relationships between these views is emphasized, as well as the process of creating accurate drawings that can guide construction.
